LD550DUN-THB8 LCD Video Wall Display 55 Inch TFT 500 Nits 1.8mm

Product Details:

Model Number: LD550DUN-THB8

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: wooden case and carton box
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 500 pcs / month

    oops...!

    no product data.

    Go to homepage

    Detail Information

    Model Number: LD550DUN-THB8 Size: 55 Inch
    Resolution: 1920*1080 Active Area: 1209.6 × 680.4 Mm
    View Angle: 89/89/89/89 Brightness: 500 Nits
    Color: 1.06B , 98% SRGB Contrast: 1000:1
    Response Time: 8ms Backlight: WLED,60K
    Splicing Seam: 1.8mm Product Name: 55 Inch Lcd Video Wall Display
    High Light:

    LD550DUN-THB8 LCD Video Wall Display

    ,

    LCD Video Wall Display 55 Inch

    ,

    1.8mm lcd wall display

    Product Description

    LD550DUN-THB8 screen 55 inch Video wall LCD splicing panel lcd screen for video wall TFT lcd module



    This LD550DUN-THB8 panel is in 55 inch with resolution 1920x1080 and 500 nits for Video Wall, splicing seam is 1.8mm(actiive to active seam)



    General Description

    The LD550DUN is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED) Local Block backlight system. The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive display type which is operating in the normally black mode. It has a 54.64 inch diagonally measured active display area with WUXGA resolution (1080 vertical by 1920 horizontal pixel array).Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arrayed in vertical stripes.Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.Therefore, it can present a palette of more than 1.06Bilion colors.It has been designed to apply the 10-bit 2-port LVDS interface.It is intended to support Public Display where high brightness, super wide viewing angle, high color gamut,



    APPLICATIONS
    Public Information Display(PID)
    High Definition Public Monitor





    Specifications
    Part Number LD550DUN-THB8
    Size 55 inch
    Resolution 1920(RGB)×1080 , FHD
    Display Mode S-IPS, Normally Black, Transmissive
    Brightness 500 cd/m² (Typ.)
    Viewing Angle 89/89/89/89 (Typ.)(CR≥10)
    Frequency 60Hz
    Lamp Type WLED, 60K hours , With LED Driver
    Signal Interface 51 pins LVDS (2 ch, 10-bit) , Connector
    Surface Antiglare (Haze 3%), Hard coating (2H)
    Storage Temp. -20 ~ 60 °C
    Operating Temp. 0 ~ 50 °C
    Weight 13.8/15.2Kgs (Typ./Max.)





    LD550DUN-THB8 LCD Video Wall Display 55 Inch TFT 500 Nits 1.8mm 0



    LD550DUN-THB8 LCD Video Wall Display 55 Inch TFT 500 Nits 1.8mm 1

    LD550DUN-THB8 LCD Video Wall Display 55 Inch TFT 500 Nits 1.8mm 2



    About Us



    HuiZhou ChuFangxinyu, Technology co was founded in 2007,we are a solution provider for all kind of LCD displays regarding Media player, android/window display, video wall. We mainly engaged in the development, design, production, sale and service of LCD products for industrial and OEM application.We offer both hardware and software supports. Our main products are LCD kits,LCD/LED monitor/TV;Advertising machine ,Open Frame Monitors,Panel PC; Our product range has been enlarged. Our products can be widely used in OEM Application, Design Engineering, Sale, Information, Industrial Automation, Security, Hospitality, Kiosk, Home Automation, Gaming Machines, ATM/Banking, Service, Testing Equipment and Monitoring, Embedded Application, Automobiles and many other industrial applications by Hobbyists, Brokers and Resellers. Our products have been exported to Germany, the UK, the USA, Italy, Australia and many other countries and regions.
